INTRODUCTION

You ran 14-gauge wire to your new water pump.

You felt capable. You felt thrifty. You felt like 14-gauge was plenty because the hardware store said it handles 15 amps.

The pump worked. For a week.

Then it started humming louder. The lights in your house flickered when it cycled on.

Month two: The pump overheated. The thermal cutoff tripped every afternoon.

Month three: The motor burned out. Smoke. $400 replacement. Plus the flooded basement when the backup failed.

You blamed the pump brand. "Chinese junk."

You bought a premium pump. American-made. $650.

You wired it with the same 14-gauge cable. It died in six weeks.

You blamed the electrician who installed the panel. "Bad breaker."

But the real problem was the number.

The wire was too thin for the distance. It did not know your pump was 180 feet from the panel. It did not know 14-gauge copper loses 0.8 volts every 10 feet under load. It did not know your pump was receiving 98 volts instead of 120.

Your motor was starving. Low voltage causes high amperage. High amperage creates heat. Heat destroys insulation.

This is what happens when you wire without a Voltage Drop Calculator.

Voltage drop is the silent killer of electrical systems.

It does not trip breakers. It does not show up until the damage is done. It hides behind "working" equipment that is actually dying.

For every 1% of voltage lost, a motor runs hotter. A light dims. An inverter shuts down. A battery bank undercharges.

At 5% drop, motors lose torque and pull 10% more current. At 10% drop, electronic ballasts fail. At 15% drop, fire risk emerges from overheated conductors.

A Voltage Drop Calculator finds that number. It tells you the exact voltage at the end of the wire. The exact wire size you need. The exact NEC compliance status.

In 2026, with solar installs running 200-foot DC lines, EV chargers pulling 48 amps, and workshop tools placed far from panels, knowing your voltage drop is not optional.

It is essential for every electrician, homeowner, solar installer, and anyone who runs wire farther than 50 feet.

---

WHAT IS A VOLTAGE DROP CALCULATOR?

A Voltage Drop Calculator is a tool that calculates the loss of electrical potential as current travels through a conductor over distance.

It uses electrical engineering principles and the National Electrical Code (NEC) standards:

• Ohm's Law — Voltage = Current × Resistance

• NEC Chapter 9, Table 8 — Conductor properties (circular mils, ohms per foot)

• NEC 210.19(A) — Maximum 3% drop on branch circuits

• NEC 215.2(A) — Maximum 5% total drop (feeder + branch)

• IEEE standards — Motor circuits should not exceed 5% under load

Standard inputs:

• Voltage (120V, 240V, 480V, 12V DC, 24V DC, 48V DC)

• Current (Amps) — Load rating or measured draw

• One-way distance — Length from source to load (feet)

• Wire material — Copper or Aluminum

• Wire size — AWG or kcmil

• Temperature — 75°C standard, or custom

• Phase — Single-phase or three-phase

• Power factor — For AC loads (default 1.0 for resistive, 0.85 for motors)

Outputs you get:

• Voltage drop in volts

• Percentage drop

• Voltage at load (what the device actually receives)

• NEC compliance (pass/fail for 3% and 5% limits)

• Recommended minimum wire size for your run

• Power loss in watts

• Energy cost of the loss (annual)

• Wire resistance for the run

It answers the questions every installer asks:

"Why does my pump keep burning out?"

"Will 12-gauge wire handle my EV charger 80 feet from the panel?"

"Why do my solar panels show low voltage at the inverter?"

"Is my workshop subpanel legal and safe?"

---

HOW TO USE THE NUMOVIX VOLTAGE DROP CALCULATOR

Our calculator gives you instant, accurate voltage loss analysis in under 30 seconds.

Step 1:

Select your system type (AC or DC) and phase.

Example: AC Single-Phase

---

Step 2:

Enter your source voltage.

Example: 120 volts

---

Step 3:

Enter your load current in amps.

Example: 12 amps (1 HP sump pump)

---

Step 4:

Enter your one-way wire distance in feet.

Example: 180 feet (from panel to pump)

---

Step 5:

Select your wire material and wire size.

Example: Copper, 14 AWG

---

Step 6:

Enter power factor (for AC motors).

Example: 0.85

---

Step 7:

Click "Calculate Voltage Drop."

You will instantly see:

Example: 120V, 12A, 180 ft, Copper 14 AWG, Single-Phase

---

Voltage Drop Results:

| Parameter | Value |

| Voltage Drop | 11.2 volts |

| Percentage Drop | 9.3% |

| Voltage at Load | 108.8 volts |

| NEC 3% Limit | FAIL (exceeds 3.6V) |

| NEC 5% Limit | FAIL (exceeds 6.0V) |

| Power Loss | 134.4 watts |

| Annual Energy Waste | 1,177 kWh |

| Wire Resistance | 0.933 ohms |

---

Recommendation:

| 10 AWG | 4.5V | 3.75% | Marginal |

| 8 AWG | 2.8V | 2.33% | PASS |

| 6 AWG | 1.8V | 1.50% | Excellent |

---

Key Numbers:

• Actual voltage at pump: 108.8V (pump rated for 115–120V)

• Motor damage threshold: Below 110V sustained = overheating

• Code requirement: 3% max for branch circuits

• **Required wire:** 8 AWG minimum for this run

• Cost difference: 14 AWG = $45. 8 AWG = $180. Pump replacement = $400.

• Payback: One saved motor pays for the thicker wire twice over.

---

Example: EV Charger — 240V, 48A, 75 ft, Copper, Three-Phase

| 8 AWG | 7.2V | 3.0% | 232.8V | PASS |

| 6 AWG | 4.5V | 1.88% | 235.5V | Excellent |

| 4 AWG | 2.8V | 1.17% | 237.2V | Overkill |

Recommendation: 6 AWG copper for optimal efficiency and safety margin.

---

THE MATH BEHIND VOLTAGE DROP CALCULATION

Understanding the formulas helps you verify results and avoid code violations.

---

Single-Phase AC / DC Formula:

VD = (2 × K × I × L) ÷ CM

Where:

• VD = Voltage Drop (volts)

• K = Conductor resistivity constant (12.9 for copper at 75°C, 21.2 for aluminum at 75°C)

• I = Current (amps)

• L = One-way length (feet)

• CM = Circular Mils of the conductor

---

Three-Phase AC Formula:

VD = (1.732 × K × I × L) ÷ CM

The 1.732 factor is the square root of 3, accounting for three-phase geometry.

---

Circular Mils (CM) by Wire Size:

| AWG | Circular Mils | Ohms/1000 ft (Cu, 75°C) |

| 14 | 4,110 | 3.07 |

| 12 | 6,530 | 1.93 |

| 10 | 10,380 | 1.21 |

| 8 | 16,510 | 0.764 |

| 6 | 26,240 | 0.491 |

| 4 | 41,740 | 0.308 |

| 2 | 66,360 | 0.194 |

| 1/0 | 105,600 | 0.122 |

| 2/0 | 133,100 | 0.096 |

---

Complete Calculation Example:

Scenario: 120V, 12A, 180 ft, Copper 14 AWG, Single-Phase

VD = (2 × 12.9 × 12 × 180) ÷ 4,110

VD = (2 × 12.9 × 2,160) ÷ 4,110

VD = 55,728 ÷ 4,110

VD = 13.56 volts (theoretical)

Note: With power factor 0.85 and impedance adjustments, actual drop is ~11.2V. The calculator uses precise impedance values from NEC Chapter 9.

---

Percentage Drop:

% Drop = (VD ÷ Source Voltage) × 100

Example:

(11.2 ÷ 120) × 100 = 9.33%

---

Power Loss:

P = I² × R or P = VD × I

Example:

11.2V × 12A = 134.4 watts wasted as heat

Annual waste (running 8 hours/day):

134.4W × 8 hrs × 365 days = 392,448 Wh = 392.4 kWh

At $0.15/kWh: $58.86 per year in wasted electricity.

---

Complete Real Example:

Arjun's Workshop Subpanel:

Starting Point:

• Detached workshop: 180 feet from main panel

• Planned loads: Table saw (15A), dust collector (12A), lights (8A), heater (20A)

• Total simultaneous load: 35 amps (diversity factor applied)

• Voltage: 240V single-phase

• Wire initially planned: 10 AWG copper (because "it handles 30 amps")

---

Month 1: The Guess Approach

Arjun runs 10 AWG THHN underground in PVC conduit. Cost: $120.

He installs the subpanel. Everything works. For a month.

Then the table saw bogs down on hardwood. The dust collector trips thermal overload. The heater cycles erratically.

He checks voltage at the subpanel: 218 volts under 35-amp load.

Source is 240V. Drop is 22 volts = 9.2%.

He blames the table saw motor. Replaces it. $320.

He blames the dust collector. Replaces it. $280.

He adds a "voltage booster" from an online ad. $150. It catches fire.

Net result: $750 wasted. Plus fire risk. Plus the 10 AWG wire is now permanently undersized and buried.

---

Month 4: Discovers the Calculator

Arjun uses the Numovix Voltage Drop Calculator.

Original Design (10 AWG):

• VD = (2 × 12.9 × 35 × 180) ÷ 10,380

• VD = 162,540 ÷ 10,380

• VD = 15.6 volts

• % Drop = 15.6 ÷ 240 = 6.5%

• Voltage at subpanel: 224.4V (no-load even worse due to impedance)

Under 35A load: Actual measured 218V = 9.2% (accounting for temperature, connections, and power factor).

NEC Compliance:

• Feeder limit: 5% max. FAIL.

• Branch circuit limit: 3% max. FAIL.

He realizes:

• 10 AWG is rated for 30 amps in ampacity, but not for 180 feet at 35 amps.

• Ampacity ≠ voltage drop compliance. A wire can handle the current without melting but still fail code and damage equipment.

• His motors were receiving 218V. Below the 230V minimum for 240V motors. Low voltage = high current = overheating.

---

New Approach:

He recalculates for proper wire size.

Target: < 3% drop (7.2V max) for feeder + branch combined, or < 5% (12V) for feeder alone.

Option A: 6 AWG Copper

• VD = (2 × 12.9 × 35 × 180) ÷ 26,240

• VD = 162,540 ÷ 26,240

• VD = 6.2 volts

• % Drop = 2.58%

• Status: PASS (excellent)

Option B: 4 AWG Aluminum

• K = 21.2

• VD = (2 × 21.2 × 35 × 180) ÷ 41,740

• VD = 267,120 ÷ 41,740

• VD = 6.4 volts

• % Drop = 2.67%

• Status: PASS (cost-effective)

He chooses 4 AWG aluminum URD cable (underground rated). Cost: $340.

He pulls out the 10 AWG. Installs the 4 AWG.

Results after installation:

• Subpanel voltage under full 35A load: 237.2V

• Drop: 2.8V = 1.17%

• Table saw: Full torque. No bogging.

• Dust collector: No thermal trips.

• Heater: Steady cycling.

• Annual power loss reduced from 1,200W to 98W.

He spent $220 more on wire and saved $750 in equipment plus $85/year in wasted electricity.

Why? Because he respected voltage drop.

---

VOLTAGE DROP BY APPLICATION

| General outlet | 120V, 15A | 50 ft | 80 ft | NEC 3% limit |

| Refrigerator | 120V, 6A | 100 ft | 160 ft | Dedicated circuit recommended |

| Sump pump | 120V, 10A | 60 ft | 95 ft | Critical: low voltage kills motors |

| Water heater | 240V, 25A | 70 ft | 110 ft | 10 AWG common, check distance |

| EV charger (32A) | 240V, 32A | 45 ft | 70 ft | 6 AWG recommended for 50+ ft |

| EV charger (48A) | 240V, 48A | 30 ft | 50 ft | 4 AWG for 75+ ft |

| Solar DC (12V) | 12V, 10A | 15 ft | 25 ft | DC drops faster; 2% target |

| Solar DC (48V) | 48V, 10A | 60 ft | 95 ft | Use 2% limit for battery health |

| Well pump | 240V, 15A | 90 ft | 140 ft | 8 AWG for 200+ ft |

| HVAC condenser | 240V, 25A | 70 ft | 110 ft | Compressor sensitive to drop |

| Subpanel (60A) | 240V, 60A | 40 ft | 65 ft | 4 AWG or 2 AWG typical |

| Subpanel (100A) | 240V, 100A | 25 ft | 40 ft | 1/0 or 2/0 required |

---

WHY EVERY INSTALLER NEEDS A VOLTAGE DROP CALCULATOR

1. Know Your Real Voltage

A motor nameplate says 115V. Your panel delivers 120V. But after 150 feet of 14-gauge wire, the motor sees 108V.

It does not stop. It suffers. The calculator shows the truth at the load.

---

2. Stop Burning Up Motors

Low voltage is the #1 cause of motor failure.

A 10% drop causes motors to pull 10–15% more current. Heat rises exponentially.

The calculator prevents this before you pull wire.

---

3. Pass Inspection

Inspectors check wire size against load and distance.

If your 200-foot run of 12 AWG to a barn drops 8%, you fail. You rip it out. You re-buy. You re-dig.

The calculator ensures first-time compliance.

---

4. Save Energy

Voltage drop is literally electricity turned into heat in the wire.

A 5% drop on a 30-amp, 240V circuit wastes 360 watts continuously.

That is 3,150 kWh per year running 24/7. $472 at $0.15/kWh.

Thicker wire pays for itself.

---

5. Protect Electronics

Inverters, chargers, and VFDs shut down on low voltage.

Your $2,000 solar inverter throws fault codes. Your EV charger throttles to 16 amps.

The calculator sizes wire for the actual voltage required.

---

6. Size Wire Before You Buy

Copper prices fluctuate. Aluminum may be code-compliant and cheaper.

The calculator lets you compare copper vs. aluminum for the same drop target.

---

7. Understand Why Your Neighbor's Pump Lasts Longer

Your neighbor: Ran 8 AWG 200 feet. Drop is 2.1%. Pump receives 235V. Motor runs cool.

You: Ran 12 AWG 200 feet. Drop is 7.8%. Pump receives 221V. Motor runs hot.

Same pump. Different wire. Different lifespan.

The calculator explains the difference.

---

KEY FACTORS THAT AFFECT VOLTAGE DROP

Wire Size (AWG):

Larger wire = more circular mils = less resistance = less drop.

Doubling wire size roughly halves voltage drop.

But larger wire costs more. The calculator finds the minimum compliant size.

---

Distance:

Voltage drop is directly proportional to length.

Double the distance = double the drop.

This is why long runs to outbuildings, gates, pumps, and solar arrays require upsizing.

---

Current (Amps):

Higher current = higher drop.

A 20-amp load drops twice as much as a 10-amp load on the same wire.

Always use actual running amps, not breaker size.

---

Wire Material:

• Copper: K = 12.9. Lower resistance. More expensive.

• Aluminum: K = 21.2. Higher resistance. 66% heavier gauge needed for same drop. Cheaper.

Example: 6 AWG copper = 4 AWG aluminum for similar drop.

---

Temperature:

Wire resistance increases with temperature.

• At 30°C ambient: Standard values apply

• At 50°C ambient (attic, conduit in sun): Resistance increases 8%

• At 75°C conductor temp: NEC standard values

Hot environments need upsizing.

---

Power Factor:

Motors and fluorescent loads have power factor < 1.0 (typically 0.8–0.9).

Low power factor increases reactive voltage drop.

The calculator applies power factor correction for AC motor circuits.

---

System Voltage:

Lower voltage = worse drop percentage.

• 10V drop on 120V = 8.3% (FAIL)

• 10V drop on 480V = 2.1% (PASS)

This is why 240V tools tolerate longer runs better than 120V tools.

DC systems (12V, 24V, 48V) are especially sensitive.

---

Connections and Terminals:

Every splice, terminal, and receptacle adds resistance.

Poor connections can add 0.5–2% drop beyond wire calculations.

The calculator assumes proper terminations per NEC.

---

COMMON MISTAKES PEOPLE MAKE

Mistake 1: Using Ampacity Charts Alone

"10 AWG handles 30 amps. I'm good."

Ampacity prevents fire. It does not prevent voltage drop.

A 30-amp load on 10 AWG at 200 feet drops 18 volts. 7.5% on 240V. FAIL.

Always check drop after checking ampacity.

---

Mistake 2: Measuring Straight-Line Distance

You measure 150 feet on a map. The wire runs up, over, around, down.

Actual wire path: 210 feet.

You size for 150. You fail.

Measure the actual wire path, not the point-to-point distance.

---

Mistake 3: Ignoring Return Path

Voltage drop happens on both hot and neutral (single-phase) or all three conductors (three-phase).

The "2×" and "1.732×" factors in the formula account for this.

Do not calculate one-way and forget the return.

---

Mistake 4: Using Breaker Size Instead of Load Current

You install a 20-amp breaker. You calculate drop at 20 amps.

Actual load: 7 amps (LED shop lights).

You oversize wire and waste money.

Calculate at actual running amps, not breaker rating.

---

Mistake 5: Treating DC Like AC

DC voltage drop uses the same formula but lower voltage systems are less forgiving.

A 2% drop target is standard for 12V and 24V DC (solar, battery, RV).

Using AC rules for DC solar runs destroys battery charging efficiency.

---

Mistake 6: Not Accounting for Inrush Current

Motors draw 3–6× running amps at startup.

A sump pump runs at 10A but starts at 50A.

The wire must handle the momentary drop. If startup voltage falls below 108V on 120V, the motor stalls and burns.

Size wire for inrush, not just steady-state.

---

Mistake 7: Assuming Copper Is Always Better

Copper is better conductor. But 2/0 aluminum is cheaper than 1 AWG copper and carries the same load with less drop.

For long runs, aluminum is code-compliant and cost-effective when sized correctly.

Use antioxidant paste on terminations.

---

PRO TIPS TO USE VOLTAGE DROP EFFECTIVELY

Tip 1: Calculate at the Load, Not the Panel

Your panel reads 121V. Your load is 180 feet away.

The calculator tells you the voltage at the device. That is the only number that matters.

---

Tip 2: Use 2% Target for Critical Loads

NEC allows 3% on branch circuits. But for motors, pumps, and electronics, design for 2%.

The extra cost in wire is insurance against equipment failure.

---

Tip 3: Size for the Future

Running wire to a shed? You have 20 amps today. You might add a welder tomorrow.

Size the feeder for 50 amps. Use a smaller breaker now.

Wire is cheap when the trench is open. Expensive when you have to re-dig.

---

Tip 4: Compare Copper vs. Aluminum

For runs over 100 feet, price both.

• 4 AWG copper URD: $450

• 2 AWG aluminum URD: $280

Both pass code. Both pass drop. One saves $170.

---

Tip 5: Use Higher Voltage When Possible

A 240V compressor on 10 AWG at 200 feet drops 4.2%.

The same load at 120V on 10 AWG at 200 feet drops 8.4%.

Double the voltage = half the percentage drop.

Use 240V for long runs whenever possible.

---

Tip 6: Check Voltage Under Load

Use a multimeter at the load while it runs.

Compare measured drop to calculated drop. If measured is 2× calculated, you have a bad connection.

Loose terminals create resistance. They generate heat. They start fires.

---

Tip 7: Document Your Calculations

Save the calculator output. Attach it to your permit application.

Inspectors appreciate documented engineering. Home buyers appreciate knowing the system is properly sized.

---

QUICK SUMMARY

Before you use the calculator, remember these key points:

• Voltage drop = wasted electricity turned into heat — it costs money and damages equipment

• NEC limit: 3% on branch circuits, 5% total (feeder + branch) — this is code, not suggestion

• Ampacity ≠ voltage drop — a wire can carry the current without melting but still fail drop requirements

• Distance is the enemy — double the run = double the drop

• Lower voltage = less tolerance — 12V DC needs 2% target, not 3%

• Motors are most sensitive — low voltage causes high current, overheating, and premature death

• Always measure actual wire path — not straight-line distance

• Calculate at running amps, not breaker size — unless sizing for future loads

• Copper vs. aluminum — aluminum is 66% the conductivity; upsize one gauge for equivalent drop

• Temperature matters — hot attics and conduits increase resistance

• Power factor affects AC motors — use 0.85 for motors, 1.0 for resistive loads

• Inrush current matters — startup amps can be 6× running amps

• Thicker wire pays for itself — saved equipment + energy often exceeds wire cost

---

FREQUENTLY ASKED QUESTIONS

Q1: What is voltage drop and why does it matter?

Voltage drop is the reduction in electrical potential as current flows through a conductor due to resistance.

It matters because:

• Motors overheat and fail on low voltage

• Lights dim and flicker

• Electronics shut down or malfunction

• Energy is wasted as heat in the wire

• NEC requires limits to ensure safety and efficiency

---

Q2: What is the maximum allowed voltage drop?

NEC recommends:

• 3% on branch circuits (outlets, lights, dedicated loads)

• 5% total from service entrance to final outlet

Best practice for sensitive equipment: 2% or less.

---

Q3: Why does my motor burn out even though the wire is "big enough"?

Because ampacity (current-carrying capacity) is different from voltage drop compliance.

A wire may handle 20 amps without overheating, but after 150 feet, the voltage at the motor is too low.

Low voltage causes motors to pull more current to maintain power. More current = more heat = insulation failure.

---

Q4: Can I use aluminum wire instead of copper?

Yes, when properly sized and terminated.

Aluminum has higher resistance, so you must upsize.

Example: If 8 AWG copper is required, use 6 AWG aluminum.

Always use antioxidant compound on aluminum terminations. Torque to manufacturer specs.

---

Q5: How do I calculate voltage drop for a solar panel array?

Solar arrays output DC at low voltage (12V, 24V, 48V).

Use the DC formula: VD = (2 × K × I × L) ÷ CM

Use a 2% maximum drop target because:

• Battery charging efficiency suffers

• Low voltage triggers inverter shutdowns

• MPPT controllers need stable voltage

For long runs, use higher array voltage (series strings) or thicker wire.

---

Q6: Does a voltage drop calculator replace an electrician?

No. It informs you and your electrician.

Use it to:

• Verify contractor bids

• Plan DIY projects within your skill level

• Understand why equipment fails

• Size wire before calling for quotes

Always hire a licensed electrician for panel work, underground runs, and code compliance verification.

---

Q7: Why does my voltage drop calculation differ from my multimeter reading?

Possible causes:

• Connections: Loose terminals add resistance

• Temperature: Hot wire = higher resistance

• Power factor: Motors draw reactive current

• Harmonics: Non-linear loads distort readings

• Measurement error: Multimeter accuracy and lead resistance

If measured drop exceeds calculated by more than 20%, inspect all connections.

---

RELATED CALCULATORS

Explore our full suite of free electrical and engineering tools:

• Wire Size Calculator

• Ampacity Calculator

• Conduit Fill Calculator

• Electrical Load Calculator

• Solar Panel Calculator

• Battery Bank Calculator

• EV Charger Calculator

• Ohm's Law Calculator

• Power Factor Calculator

• Electricity Cost Calculator

---

FINAL THOUGHTS

Electricity does not forgive thin wire.

It does not care about your budget. It does not care about your timeline. It does not care about your good intentions.

It only cares about resistance. Distance. Current. Heat.

The Voltage Drop Calculator does not pull the wire.

It guides you.

It tells you: "This is the drop. This is the code limit. This is where 14-gauge ends and 8-gauge begins. This is where guessing ends and engineering begins."

Below the right wire size, you are not saving money. You are building a fire hazard and an equipment graveyard.

At the right size, with proper connections, you are optimizing.

Motors run cool. Lights stay bright. Inverters stay online. Energy is not wasted as heat in the dirt.

Before you buy another spool of wire, calculate your voltage drop.

Before you bury cable in a trench you will never reopen, calculate your voltage drop.

Before you wonder why your third pump burned out this year, calculate your voltage drop.

Know your drop. Respect the distance. Size your conductors from a place of precision, not thrift.

That is how you wire without regret.

That is how you pass inspection the first time.

That is how you build a system that lasts for decades.

---

DISCLAIMER

This article is for educational and informational purposes only.

Voltage drop calculations, wire sizing, and electrical guidelines are general estimates and vary significantly by local electrical codes, ambient conditions, installation methods, and equipment specifications.

The examples provided are illustrative and based on standard electrical engineering practices (NEC, IEEE, Ohm's Law).

Actual voltage drop depends on:

• Exact wire type and insulation rating

• Termination quality and connection resistance

• Ambient temperature and conduit fill

• Actual load current vs. estimated

• Power factor and harmonic content

• Local amendments to the National Electrical Code

Always consult a licensed electrician or electrical engineer before installing, modifying, or sizing electrical circuits, especially for underground runs, subpanels, motor circuits, and high-current loads.

Numovix does not provide electrical engineering, installation, or code compliance advice.

Our calculator results are estimates and should not replace professional electrical design or inspection.

If you experience symptoms of electrical problems (flickering lights, burning smells, warm outlets, frequently tripping breakers, or equipment failures), de-energize the circuit and contact a licensed electrician immediately.

Voltage Drop Calculator | Calculate Wire Size, Voltage Loss & NEC Compliance | Numovix

Free voltage drop calculator. Calculate exact voltage loss for copper and aluminum wire runs. Check NEC compliance, find minimum wire gauge, and prevent motor burnout and dimming lights. No signup needed.
