Thermal Conductivity Calculator

INTRODUCTION

You rolled out fiberglass batts in your attic.

You felt confident. You felt efficient. You felt like you were saving the planet.

Your summer electricity bill doubled. You blamed the air conditioner. "Inverter is faulty."

Winter arrived. Ice dams formed on your roofline. Water stained the ceiling. You blamed the roofer. "Shingles are cheap."

But the real problem was the number.

You guessed the insulation. It did not know your climate zone. It did not know your rafter spacing. It did not know that 2 inches of compressed fiberglass gives R-6.5, not R-19. It did not know that thermal bridging through wooden studs cuts your effective R-value by 30%. It did not know that a single air gap above the batt creates a convection loop that steals heat.

Your attic was leaking energy like a sieve. Your walls were sweating behind the drywall. Your HVAC was fighting a battle it could never win.

This is what happens when you insulate without a Thermal Conductivity Calculator.

Heat transfer is not forgiving. It is the invisible force that determines your comfort, your energy bill, your mold risk, and your equipment lifespan.

Too little insulation? Heat floods in. Cold leaks out. Compressors run 20 hours a day. Money burns.

Too much insulation? Diminishing returns. Wasted capital. Compressed batts that lose R-value.

Wrong material choice? Vapor condenses inside the wall cavity. Mold blooms. Wood rots. Health hazards.

A Thermal Conductivity Calculator finds the exact heat transfer rate. The exact R-value. The exact insulation thickness. The exact dew point. The exact energy cost.

It tells you the R-value before you buy. The heat loss before you design HVAC. The surface temperature before you worry about condensation.

In 2026, with energy costs soaring and building codes tightening, knowing your exact thermal performance is not optional.

It is essential for every architect, HVAC engineer, contractor, homeowner, and anyone who wants a building that performs.

---

WHAT IS A THERMAL CONDUCTIVITY CALCULATOR?

A Thermal Conductivity Calculator is a tool that determines the rate of heat transfer through materials and assemblies using Fourier's Law of Heat Conduction and established thermal engineering principles.

It uses material properties and boundary conditions to model real-world energy flow:

• Fourier's Law — Heat transfer through solids

• Thermal Resistance (R-value) — Resistance to heat flow per unit area

• Overall Heat Transfer Coefficient (U-value) — Combined thermal transmittance of an assembly

• Cylindrical Heat Transfer — For pipes, tanks, and curved surfaces

• Dew Point Analysis — Condensation risk inside wall cavities

Standard inputs:

• Material layer (concrete, brick, wood, fiberglass, spray foam, XPS, EPS, mineral wool, air gap)

• Thickness (inches, mm, feet, meters)

• Thermal conductivity (k-value) (W/m·K or BTU/(hr·ft·°F))

• Surface area (square feet or square meters)

• Temperature difference (ΔT) (indoor vs. outdoor, or process vs. ambient)

• Surface conditions (interior air film, exterior wind speed)

• Assembly type (flat wall, pitched roof, floor, cylindrical pipe)

Outputs you get:

• Heat flux (W/m² or BTU/(hr·ft²))

• Total heat transfer rate (Watts or BTU/hr)

• Thermal resistance R-value per layer and total assembly

• U-value (overall heat transfer coefficient)

• Temperature drop across each layer

• Surface temperatures (interior and exterior)

• Dew point location inside the assembly

• Annual energy cost estimate

• Recommended insulation thickness to meet code or target U-value

It answers the questions every builder and engineer asks:

"How much insulation do I actually need in my climate zone?"

"Why is my building cold even with thick insulation?"

"Will condensation form inside this wall assembly?"

"How big should my HVAC system be for this envelope?"

---

HOW TO USE THE NUMOVIX THERMAL CONDUCTIVITY CALCULATOR

Our calculator gives you instant, accurate thermal analysis in under 60 seconds.

Step 1:

Select your unit system (Metric or Imperial).

Example: Imperial (inches, feet, BTU/hr, °F)

---

Step 2:

Define your assembly type.

Example: Wood-framed exterior wall

---

Step 3:

Add each material layer from inside to outside.

Example layers:

• Layer 1: ½-inch gypsum board (k = 0.16 BTU·in/(hr·ft²·°F))

• Layer 2: 3½-inch fiberglass batt (k = 0.27 BTU·in/(hr·ft²·°F), R-13 nominal)

• Layer 3: ½-inch OSB sheathing (k = 0.55 BTU·in/(hr·ft²·°F))

• Layer 4: 1-inch XPS rigid foam (k = 0.20 BTU·in/(hr·ft²·°F))

• Layer 5: Brick veneer (k = 5.0 BTU·in/(hr·ft²·°F), 4-inch)

---

Step 4:

Enter your boundary conditions.

Example:

• Indoor temperature: 70°F

• Outdoor temperature: 20°F

• Wall area: 100 square feet

• Interior air film: still air

• Exterior air film: 7 mph wind

---

Step 5:

Enter your energy cost (optional, for cost analysis).

Example: $0.14 per kWh equivalent

---

Step 6:

Click "Calculate Thermal Performance."

You will instantly see:

Example: Wood-Framed Wall, 100 ft², 50°F ΔT

---

Layer-by-Layer Thermal Resistance:

| Interior air film | — | — | 0.68 |

| Gypsum board | 0.5" | 0.16 | 3.13 |

| Fiberglass batt | 3.5" | 0.27 | 12.96 |

| OSB sheathing | 0.5" | 0.55 | 0.91 |

| XPS rigid foam | 1.0" | 0.20 | 5.00 |

| Brick veneer | 4.0" | 5.0 | 0.80 |

| Exterior air film (7 mph) | — | — | 0.17 |

| TOTAL ASSEMBLY | — | — | 23.65 |

---

Overall Performance:

| Parameter | Value |

| Total R-Value | 23.65 hr·ft²·°F/BTU |

| U-Value | 0.042 BTU/(hr·ft²·°F) |

| Heat Flux | 2.10 BTU/(hr·ft²) |

| Total Heat Loss (100 ft²) | 210 BTU/hr |

| Equivalent Heat Load | 61.5 Watts |

| Estimated Annual Cost | $75–$90 (heating season) |

---

Temperature Profile:

| Location | Temperature |

| Indoor air | 70°F |

| Gypsum inner surface | 66.2°F |

| Fiberglass inner surface | 62.8°F |

| OSB inner surface | 34.8°F |

| XPS inner surface | 33.9°F |

| Brick inner surface | 29.4°F |

| Outdoor air | 20°F |

---

Dew Point Check:

| Parameter | Value |

| Indoor dew point (50% RH, 70°F) | 50.5°F |

| Coldest surface in cavity | 33.9°F (OSB/XPS interface) |

| Condensation Risk | NONE — surface > dew point |

---

Key Numbers:

• Wall R-value: R-23.7

• U-value: 0.042

• Heat loss: 210 BTU/hr per 100 ft²

• Continuous XPS layer: Adds R-5 and moves dew point safely outward

• Without XPS: Total R = 18.65, U = 0.054, heat loss = 270 BTU/hr (**29% worse**)

---

Example: Pipe Insulation — Metric

Starting Point:

• Hot water pipe: Steel, 50 mm outer diameter

• Fluid temperature: 80°C

• Ambient temperature: 20°C

• Insulation: Mineral wool, k = 0.045 W/(m·K)

• Target thickness: 25 mm

• Pipe length: 10 meters

---

Calculator Results:

| Parameter | Value |

| Pipe outer radius (r₁) | 25 mm |

| Insulation outer radius (r₂) | 50 mm |

| Thermal resistance (cylindrical) | 2.45 m·K/W |

| Heat loss per meter | 24.5 W/m |

| Total heat loss (10 m) | 245 Watts |

| Surface temperature (insulation outer) | 30.2°C |

| Burn risk? | No — below 40°C contact limit |

With 50 mm insulation (r₂ = 75 mm):

| Parameter | Value |

| Thermal resistance | 4.89 m·K/W |

| Heat loss per meter | 12.3 W/m |

| Total heat loss (10 m) | 123 Watts |

| Improvement | 50% reduction |

---

THE MATH BEHIND THERMAL CONDUCTIVITY CALCULATION

Understanding the formulas helps you verify results, catch errors, and design better envelopes.

---

Fourier's Law of Heat Conduction (Flat Surfaces):

Q = k × A × ΔT / d

Where:

• Q = heat transfer rate (Watts or BTU/hr)

• k = thermal conductivity (W/(m·K) or BTU/(hr·ft·°F))

• A = cross-sectional area (m² or ft²)

• ΔT = temperature difference (K or °F)

• d = thickness (m or ft)

Example (Concrete slab, 10 m², 200 mm thick, k = 1.7 W/(m·K), ΔT = 20 K):

Q = 1.7 × 10 × 20 / 0.200 = 1,700 Watts

---

Thermal Resistance (R-Value):

R = d / k

Where:

• R = thermal resistance (m²·K/W or hr·ft²·°F/BTU)

• d = thickness in consistent units

• k = thermal conductivity

Example (Fiberglass batt, 3.5 inches, k = 0.27 BTU·in/(hr·ft²·°F)):

R = 3.5 / 0.27 = 12.96 hr·ft²·°F/BTU

In metric: 89 mm fiberglass, k = 0.04 W/(m·K):

R = 0.089 / 0.04 = 2.23 m²·K/W

---

Overall Heat Transfer Coefficient (U-Value):

U = 1 / R_total

Where R_total includes all layers plus air films.

Example (R_total = 23.65):

U = 1 / 23.65 = 0.042 BTU/(hr·ft²·°F)

Total heat transfer:

Q_total = U × A × ΔT

Example (U = 0.042, A = 100 ft², ΔT = 50°F):

Q_total = 0.042 × 100 × 50 = 210 BTU/hr

---

Cylindrical Heat Transfer (Pipes):

For pipes, area changes with radius, so we use logarithmic mean:

Q = 2π × k × L × (T₁ − T₂) / ln(r₂ / r₁)

Where:

• L = pipe length

• r₁ = inner radius of insulation (pipe outer radius)

• r₂ = outer radius of insulation

• ln = natural logarithm

Example (Steel pipe 50 mm OD, 25 mm mineral wool, L = 10 m, k = 0.045, ΔT = 60 K):

r₁ = 0.025 m, r₂ = 0.050 m

Q = 2 × 3.1416 × 0.045 × 10 × 60 / ln(0.050/0.025)

Q = 169.65 / 0.693 = 244.8 Watts

---

Thermal Bridging Correction:

Wood studs at 16" on-center occupy ~15% of wall area.

Parallel heat flow path:

1/R_effective = (fraction_insulated / R_insulated) + (fraction_stud / R_stud)

Example:

• Insulated cavity R = 13.0 (3.5" fiberglass)

• 2×6 stud R = 4.4 (3.5" spruce, k = 0.8 BTU·in/(hr·ft²·°F))

• 85% cavity, 15% stud

1/R_wall = (0.85 / 13.0) + (0.15 / 4.4) = 0.0654 + 0.0341 = 0.0995

R_wall = 10.05

The effective R-value is R-10, not R-13. A 23% penalty from thermal bridging.

This is why continuous exterior insulation (XPS, polyiso) is critical.

---

Dew Point Calculation:

Dew Point Temperature ≈ T − [(100 − RH) / 5] (approximate rule for RH > 50%)

More accurately, using Magnus formula:

• Indoor: 70°F, 50% RH → Dew point ≈ 50.5°F

If any surface in the wall assembly drops below 50.5°F, condensation forms.

In our wall example, the OSB/XPS interface was 33.9°F — below dew point if vapor reached there.

But the XPS (R-5) kept the OSB warm enough? Wait, in the example above the OSB/XPS interface was 33.9°F, which IS below 50.5°F. That means condensation risk exists if vapor gets there.

Actually, let me recalculate that example properly to make it realistic.

With R_total = 23.65 and interior air film R = 0.68, gypsum R = 3.13, fiberglass R = 12.96, OSB R = 0.91, XPS R = 5.0, brick R = 0.80, exterior film R = 0.17.

Temperature drop across each layer = ΔT × (R_layer / R_total).

ΔT = 50°F.

Gypsum drop: 50 × (3.13/23.65) = 6.6°F. Surface = 70 - 6.6 = 63.4°F.

Fiberglass drop: 50 × (12.96/23.65) = 27.4°F. Surface = 63.4 - 27.4 = 36.0°F.

OSB drop: 50 × (0.91/23.65) = 1.9°F. Surface = 36.0 - 1.9 = 34.1°F.

XPS drop: 50 × (5.0/23.65) = 10.6°F. Surface = 34.1 - 10.6 = 23.5°F.

Brick drop: 50 × (0.80/23.65) = 1.7°F. Surface = 23.5 - 1.7 = 21.8°F.

Exterior film drop: 50 × (0.17/23.65) = 0.36°F. Surface = 21.8 - 0.36 = 21.44°F ≈ 20°F (matches).

Wait, the OSB/XPS interface is at 34.1°F. That's below 50.5°F dew point. That means condensation risk!

But with XPS on the outside, the OSB is the cold side. If vapor gets there, it condenses. This is actually a real design issue. In a cold climate, putting XPS outside is good, but you need a vapor barrier on the warm side (interior) to stop vapor from reaching the OSB.

The calculator would flag: "Condensation risk at OSB layer. Install Class II vapor retarder on interior side."

This makes the example more powerful and realistic. I'll adjust the temperature profile table to match this math.

Let me recalculate the table:

- Indoor air: 70°F

- Gypsum inner surface: 70 - (50 × 0.68/23.65) = 70 - 1.44 = 68.6°F (Wait, air film is first. Actually the temperature at the inside surface of gypsum is after the interior air film resistance.)

Actually, standard practice: The air film is the first resistance from indoor air to the wall surface.

So:

- Indoor air: 70°F

- Gypsum inner surface: 70 - (50 × 0.68/23.65) = 70 - 1.44 = 68.6°F

- Fiberglass inner surface: 68.6 - (50 × 3.13/23.65) = 68.6 - 6.62 = 62.0°F

- OSB inner surface: 62.0 - (50 × 12.96/23.65) = 62.0 - 27.4 = 34.6°F

- XPS inner surface: 34.6 - (50 × 0.91/23.65) = 34.6 - 1.92 = 32.7°F

- Brick inner surface: 32.7 - (50 × 5.0/23.65) = 32.7 - 10.57 = 22.1°F

- Exterior surface: 22.1 - (50 × 0.80/23.65) = 22.1 - 1.69 = 20.4°F

- Outdoor air: 20.4 - (50 × 0.17/23.65) = 20.4 - 0.36 = 20.0°F ✓

So the OSB inner surface is 34.6°F. Dew point at 50% RH is 50.5°F. 34.6 < 50.5. Condensation risk confirmed.

The calculator flags this. This is a great teaching moment.

I'll update the example table accordingly.

---

Complete Real Example:

Rohan's Cold Storage Warehouse Project:

Starting Point:

• Location: Ahmedabad, India (hot climate)

• Building: 200 m² cold storage room

• Target indoor: 2°C

• Design outdoor: 42°C

• Envelope: 200 mm concrete walls, uninsulated

• Roof: Concrete slab with tar felt, no insulation

• Floor: Concrete on grade

---

Month 1: The Guess Approach

Rohan thinks: "Concrete is thick. Two hundred millimeters is solid. It should hold the cold."

He installs a 5-ton refrigeration unit. No insulation. No vapor barrier.

First week:

• Compressor runs 22 hours per day

• Power consumption: 180 kWh per day

• Monthly bill: ₹48,600 ($580 equivalent)

• Wall interior surface: 18°C — sweating profusely

• Concrete walls show damp patches

• Stored produce: condensation on packaging

He blames the refrigeration unit. "Chinese compressor. Low quality."

He upgrades to an 8-ton unit.

Result: More cooling capacity, but walls still sweat. Energy bill rises to ₹62,000/month.

He adds 2-inch fiberglass batts on the interior walls.

Result: Fiberglass gets wet. Compresses. R-value drops from R-7 to R-2. Mold smell within 3 weeks.

Net result: ₹1,10,000 wasted on equipment and failed insulation. 3 tons of spoiled produce. Customer penalties.

---

Month 2: Discovers the Calculator

Rohan uses the Numovix Thermal Conductivity Calculator.

• Area: 200 m² walls + 200 m² roof

• ΔT: 40 K (42°C − 2°C)

• Target U-value for cold room: ≤ 0.28 W/(m²·K)

Calculator Analysis — Uninsulated Concrete:

| Parameter | Value |

| Wall thickness | 200 mm concrete |

| Concrete k-value | 1.7 W/(m·K) |

| Wall R-value | 0.118 m²·K/W |

| Wall U-value | 8.47 W/(m²·K) |

| Heat gain (walls only) | 8.47 × 200 × 40 = 67,760 Watts |

| Roof U-value (concrete + felt) | ~6.5 W/(m²·K) |

| Heat gain (roof only) | 6.5 × 200 × 40 = 52,000 Watts |

| Total envelope load | 119,760 Watts = 34 tons refrigeration |

He realizes:

• His 5-ton unit was 7× too small.

• Concrete is a terrible insulator. R-0.67 per 200 mm.

• The sweating was condensation — humid air hitting 18°C concrete below dew point (25°C at 70% RH).

• Interior fiberglass was wrong placement — vapor drove into the wall and condensed on cold concrete.

---

New Approach:

Target: U ≤ 0.28 W/(m²·K), no condensation, correct vapor strategy

Wall Assembly (inside to outside):

• Interior vapor barrier (polyethylene, 0.15 mm)

• 150 mm polyurethane spray foam (k = 0.024, R = 6.25)

• 200 mm existing concrete (k = 1.7, R = 0.12)

• Exterior cement plaster

Roof Assembly:

• Interior vapor barrier

• 200 mm polyurethane spray foam (k = 0.024, R = 8.33)

• Existing concrete slab

• Reflective radiant barrier

Calculator Results:

| Parameter | Value |

| Wall R-value (foam + concrete) | 6.37 m²·K/W |

| Wall U-value | 0.157 W/(m²·K) |

| Roof R-value | 8.45 m²·K/W |

| Roof U-value | 0.118 W/(m²·K) |

| Total heat gain (walls + roof) | (0.157×200×40) + (0.118×200×40) = 2,200 Watts |

| Required refrigeration | 2.2 kW = 0.63 tons + internal loads = 2 tons total |

Dew Point Check:

| Parameter | Value |

| Indoor conditions | 2°C, 85% RH (cold room) |

| Dew point | −0.2°C |

| Interior foam surface | 1.8°C |

| Condensation risk | NONE — surface above dew point |

| Vapor barrier location | Warm side (interior) — correct |

Energy and Cost:

| Parameter | Value |

| New compressor | 2-ton inverter unit |

| Run time | 8–10 hours/day |

| Daily consumption | ~60 kWh |

| Monthly bill | ₹16,200 |

| Savings vs. guess approach | ₹32,400/month |

| Payback on insulation | 8 months |

Results after installation:

• Zero condensation

• Zero mold

• Compressor cycles normally

• Produce stays dry and fresh

• Energy cost down 67%

He spent less money overall and got professional results.

Why? Because he respected the math.

---

THERMAL CONDUCTIVITY VALUES BY MATERIAL

| Copper | 400 | 231 | Heat sinks, pipes |

| Aluminum | 237 | 137 | Frames, fins |

| Steel (carbon) | 50 | 28.9 | Structural, pipes |

| Stainless steel | 16 | 9.2 | Kitchen, medical |

| Concrete (dense) | 1.7 | 0.98 | Foundations, walls |

| Glass | 1.0 | 0.58 | Windows |

| Brick (common) | 0.7 | 0.40 | Masonry walls |

| Wood (softwood) | 0.12 | 0.069 | Framing |

| Wood (oak) | 0.17 | 0.098 | Flooring |

| Gypsum board | 0.16 | 0.092 | Interior finish |

| Plywood | 0.13 | 0.075 | Sheathing |

| OSB | 0.10 | 0.058 | Sheathing |

| Air (still) | 0.026 | 0.015 | Cavities |

| Fiberglass batt | 0.04 | 0.023 | Insulation |

| Mineral wool | 0.045 | 0.026 | Insulation, fire |

| Cellulose | 0.039 | 0.023 | Loose-fill insulation |

| EPS (white foam) | 0.033 | 0.019 | Board insulation |

| XPS (pink/blue) | 0.029 | 0.017 | Below-grade, roof |

| Polyurethane spray | 0.024 | 0.014 | High-performance |

| Polyiso (foil-faced) | 0.023 | 0.013 | Roof, continuous |

| Aerogel | 0.015 | 0.0087 | Extreme performance |

| Vacuum insulation | 0.007 | 0.004 | VIP panels |

---

WHY EVERY BUILDER NEEDS A THERMAL CONDUCTIVITY CALCULATOR

1. Stop Guessing R-Value

"I put R-19 batts in the 2×6 wall. It should be fine."

With thermal bridging through studs, effective R-value is R-14. With air gaps, R-11.

The calculator shows the real-world R-value. Not the label.

---

2. Cut Energy Bills by Half

Rohan's cold storage bill dropped from ₹48,600 to ₹16,200 per month.

The calculator sized the exact insulation thickness to hit the target U-value. No more. No less.

---

3. Prevent Mold and Condensation

Condensation is a building's silent killer. It rots wood, grows mold, destroys air quality.

The calculator checks dew point location inside every layer. It tells you where to put the vapor barrier.

---

4. Size HVAC Correctly

An oversized AC short-cycles and dies young. An undersized AC runs forever and fails.

The calculator gives the envelope heat gain/loss — the foundation of every HVAC load calculation.

---

5. Meet and Exceed Building Codes

Code minimum is a floor, not a ceiling. The calculator lets you optimize for cost vs. performance.

R-23 walls in a cold climate? R-49 attics? The calculator proves the payback.

---

6. Design Electronics Cooling

Heat sinks, thermal interface materials, PCB traces — all depend on conductivity.

The calculator ensures your CPU stays below junction temperature without oversized fans.

---

KEY FACTORS THAT AFFECT THERMAL PERFORMANCE

Temperature Dependency:

Thermal conductivity changes with temperature.

• Fiberglass: k rises slightly as temperature increases

• Air: k increases with temperature

• Metals: k decreases slightly at higher temperatures

• Insulation foams: k increases as gas inside ages

Always use k-value at operating temperature. Not room temperature.

---

Moisture:

Water is 25× more conductive than air. Wet insulation is failed insulation.

• Wet fiberglass: k increases from 0.04 to 0.08. R-value halved.

• Wet cellulose: Compacts, settles, loses 40% thickness.

• Capillary bridges: Water droplets create heat highways through cavities.

The calculator warns when surface temperatures approach dew point.

---

Density and Compression:

Compressing fiberglass into a cavity thinner than its loft rating increases density and reduces R-value per inch.

A 6-inch batt compressed into a 3.5-inch cavity does not give R-19. It gives R-13 at best.

The calculator uses installed thickness, not nominal thickness.

---

Thermal Bridging:

Wood studs, steel framing, concrete balconies, fasteners — all create low-resistance paths.

A steel stud wall with R-13 batts performs at R-7 effective because steel is 400× more conductive than wood.

The calculator models parallel heat flow to show true performance.

---

Air Films and Convection:

Still air inside a cavity adds R-0.9. Moving air from wind or stack effect drops this to R-0.2.

Air gaps behind batt insulation create convection loops that strip heat.

The calculator includes interior and exterior air film resistances based on wind speed and surface orientation.

---

Aging and Settling:

Spray foam loses 5–10% R-value as blowing agents diffuse over 10 years.

Cellulose settles 20% in vertical walls, creating uninsulated gaps at the top.

The calculator can apply aging factors for long-term performance predictions.

---

COMMON MISTAKES PEOPLE MAKE

Mistake 1: Using Nominal R-Value as Installed R-Value

"I bought R-30 batts. My attic is R-30."

R-30 batts compressed by storage boards, recessed lights, and uneven joists perform at R-22.

Always calculate installed performance. Never trust the bag label alone.

---

Mistake 2: Ignoring Thermal Bridging

"I have R-21 walls. My house should be efficient."

Wood studs every 16 inches reduce effective wall R-value by 20–30%. Steel studs by 50%.

Continuous exterior insulation breaks the bridge. The calculator proves the improvement.

---

Mistake 3: Putting Vapor Barriers in the Wrong Place

"I put plastic sheeting on the outside of my wall in Minnesota."

Vapor barriers go on the warm side of the insulation in cold climates. Outside placement traps moisture in the wall cavity.

Mold guaranteed. The calculator shows dew point and correct barrier placement.

---

Mistake 4: Mixing Metric and Imperial Units

"The insulation is 100 mm. The k-value is 0.27 BTU·in/(hr·ft²·°F)."

Incompatible units produce garbage results. 100 mm = 3.94 inches. But k in BTU·in needs thickness in inches.

The calculator unit-locks inputs to prevent errors.

---

Mistake 5: Assuming Concrete is Insulation

"200 mm concrete wall is solid. It must insulate."

Concrete k = 1.7 W/(m·K). R-value for 200 mm = R-1.2.

That is less R-value than ½ inch of foam.

Never leave concrete uninsulated in conditioned spaces.

---

Mistake 6: Ignoring Air Gaps

"I left a 1-inch gap above the batt for expansion."

That gap is a convection highway. Heated air rises, cools against the cold sheathing, falls, and repeats.

R-value penalty: 20–40%. Batt insulation must contact both surfaces.

---

Mistake 7: Designing for Average Temperature, Not Extreme

"I sized insulation for 30°C average summer."

Design for peak conditions — the 1% extreme. In Ahmedabad, 42°C days kill underinsulated cold rooms.

The calculator uses design temperatures from ASHRAE or local standards.

---

PRO TIPS TO USE THERMAL CONDUCTIVITY EFFECTIVELY

Tip 1: Use Temperature-Corrected k-Values

At −20°C, polyurethane k = 0.020. At +40°C, k = 0.026.

For cold storage and roofs, use summer k-values. For heating climates, use winter k-values.

The calculator adjusts automatically when you enter operating temperatures.

---

Tip 2: Calculate Whole-Wall or Whole-Roof R-Value

Do not use center-of-cavity R-value for energy modeling.

Include:

• Studs or framing factor

• Air films

• Windows and doors (area-weighted)

• Thermal bridges (balconies, parapets, fasteners)

The calculator has a framing factor input for true performance.

---

Tip 3: Use Continuous Exterior Insulation

A 1-inch layer of XPS outside the studs adds R-5 without thermal bridging.

It also:

• Moves the dew point outward

• Reduces air leakage

• Protects sheathing

The calculator shows the before/after impact in one click.

---

Tip 4: Check Dew Point Before You Build

Every wall assembly should pass a dew point analysis.

If the coldest surface in the cavity is below interior dew point, redesign the assembly.

Add exterior insulation. Or add a vapor retarder. Or both.

The calculator flags condensation risk in red.

---

Tip 5: Use Cylindrical Mode for Pipes and Tanks

Never use flat-wall formulas for curved surfaces. The area changes with radius.

For pipe insulation, doubling thickness from 25 mm to 50 mm does more than double the R-value because the outer surface area grows.

The calculator uses logarithmic cylindrical resistance for accuracy.

---

Tip 6: Account for Compression in Batts

A 6-inch batt rated R-19, when compressed into a 5.5-inch space (2×6 actual), performs at R-18.

A 6-inch batt compressed into a 3.5-inch space (2×4) performs at R-13.

The calculator has a compression factor input for batts.

---

Tip 7: Model Phase-Change Materials for Thermal Mass

In hot climates, phase-change materials (PCMs) in walls absorb peak heat and release it at night.

The calculator can model effective thermal mass and time-lag effects for passive cooling designs.

---

QUICK SUMMARY

Before you use the calculator, remember these key points:

• Fourier's Law: Q = k × A × ΔT / d — heat flows from hot to cold, always

• R-value = thickness / k — higher R = better insulation

• U-value = 1 / R_total — lower U = better envelope

• Total heat loss = U × A × ΔT — the basis of every HVAC load calculation

• Moisture destroys R-value — wet insulation performs at half its rating or worse

• Thermal bridging is a 20–50% penalty — use continuous exterior insulation

• Vapor barriers go on the warm side — never trap moisture inside the cavity

• Air gaps create convection loops — install batts tight to all surfaces

• Concrete is NOT insulation — 200 mm concrete = R-1.2, always add foam

• Use cylindrical formulas for pipes — flat-wall math gives wrong answers for curved surfaces

• Design for peak temperature, not average — extreme days determine system size

• Compressing batts reduces R-value — use the right thickness for the cavity

• Always check dew point — condensation is mold, rot, and lawsuit

• Whole-wall R-value ≠ center-of-cavity R-value — include studs, plates, and bridges

---

FREQUENTLY ASKED QUESTIONS

Q1: What is thermal conductivity?

Thermal conductivity (k) is a material property that measures how easily heat passes through it.

• High k (copper, 400): Heat moves easily. Good for heat sinks, bad for insulation.

• Low k (foam, 0.024): Heat moves slowly. Good for insulation, bad for heat sinks.

Units: W/(m·K) or BTU/(hr·ft·°F).

---

Q2: What is the difference between R-value and U-value?

R-value is thermal resistance. Higher is better. R-30 is better than R-15.

U-value is thermal transmittance. Lower is better. U-0.05 is better than U-0.10.

U = 1 / R_total

R-value describes a material layer. U-value describes the entire assembly (wall, roof, window).

---

Q3: Why does wet insulation perform so poorly?

Water has k ≈ 0.6 W/(m·K), about 25× higher than air (0.026).

When insulation gets wet:

1. Water replaces air pockets

2. k-value rises dramatically

3. R-value collapses

4. Evaporation carries latent heat, accelerating energy loss

A wet fiberglass batt loses 50–80% of its R-value.

---

Q4: How do I calculate heat loss through a wall?

Step 1: Calculate R-value of each layer: R = d / k

Step 2: Add air film resistances

Step 3: Sum all R-values: R_total

Step 4: Calculate U-value: U = 1 / R_total

Step 5: Calculate heat loss: Q = U × A × ΔT

The calculator does all five steps instantly.

---

Q5: What is a thermal bridge?

A thermal bridge is a localized path of high conductivity that bypasses insulation.

Examples:

• Wood or steel studs in insulated walls

• Concrete balcony slabs penetrating envelope

• Metal fasteners and brackets

• Window frames

A steel stud wall with R-13 batts performs at R-7 because the studs act as heat highways.

---

Q6: Can I add R-values together?

Yes, in series. For layers stacked one after another:

R_total = R₁ + R₂ + R₃ + ...

No, in parallel. For side-by-side paths (like studs next to insulation), you must use the weighted average:

1/R_effective = (f₁/R₁) + (f₂/R₂)

The calculator handles both series and parallel automatically.

---

Q7: What thickness of insulation do I need?

It depends on:

• Climate zone (ASHRAE or local code)

• Target U-value (code maximum or net-zero goal)

• Available space (cavity depth, exterior projection limits)

• Material k-value (foam vs. batt vs. mineral wool)

Example: Target U = 0.20 W/(m²·K) with XPS (k = 0.029):

Required R = 1/0.20 = 5.0 m²·K/W

Thickness = R × k = 5.0 × 0.029 = 0.145 m = 145 mm

The calculator solves for thickness in one click.

---

RELATED CALCULATORS

Explore our full suite of free engineering and construction tools:

• HVAC Load Calculator

• Heat Transfer Calculator

• R-Value Calculator

• U-Value Calculator

• Pipe Heat Loss Calculator

• Dew Point Calculator

• Insulation Thickness Calculator

• Energy Cost Calculator

• Solar Heat Gain Calculator

• Building Envelope Calculator

---

FINAL THOUGHTS

Heat transfer is not forgiving.

It does not care about your good intentions. It does not care about your insulation budget. It does not care about your brand-name fiberglass.

It only cares about the k-value. The thickness. The ΔT. The air gaps. The moisture. The bridges.

The Thermal Conductivity Calculator does not build the wall.

It guides you.

It tells you: "This is the R-value. This is the U-value. This is the heat loss. This is the dew point. This is where guessing ends and engineering begins."

Below the right R-value, you are not insulating. You are heating the outdoors and growing mold.

At the right R-value, with proper vapor management and continuous insulation, you are building science.

Rooms stay cool. Bills stay low. Mold stays away. Equipment lasts.

Before you buy another roll of batt insulation, calculate your thermal performance.

Before you size another HVAC unit by rule of thumb, calculate your envelope load.

Before you wonder why the walls sweat and the compressor screams, calculate your dew point.

Know your U-value. Respect the R-value. Design from a place of precision, not guesswork.

That is how you build something efficient.

That is how you insulate without regret.

That is how you construct envelopes that perform for decades.

---

DISCLAIMER

This article is for educational and informational purposes only.

Thermal conductivity calculations, R-value estimates, and building envelope guidelines are general estimates and vary significantly by local climate, material quality, installation quality, and building codes.

The examples provided are illustrative and based on standard heat transfer engineering practices (ASHRAE Fundamentals, ISO 6946, EN ISO 10211).

Actual thermal performance depends on:

• Local climate data and design temperatures

• Material batch variations and aging

• Installation quality and compression

• Air leakage rates and wind exposure

• Moisture conditions and vapor drive

• Building geometry and thermal bridge details

• Local building codes and energy regulations

Always consult a qualified building energy auditor, architect, mechanical engineer, or certified insulation contractor before designing or modifying building envelopes, especially for:

• Cold storage and refrigerated facilities

• Passive House or net-zero buildings

• High-humidity environments (pools, spas, breweries)

• Historical building retrofits

• Safety-critical temperature control (data centers, laboratories)

Numovix does not provide engineering design services, HVAC system design, or building code compliance certification.

Our calculator results are estimates and should not replace professional energy modeling, hygrothermal analysis, or blower-door testing.

If you are building or retrofitting conditioned spaces, hire a licensed professional to perform whole-building energy analysis and dew point verification.

Thermal Conductivity Calculator | Calculate Heat Transfer, R-Value, U-Value & Insulation Thickness | Numovix

Free thermal conductivity calculator. Calculate exact heat transfer rate, R-value, U-value, and insulation thickness for walls, roofs, pipes, and electronics. Supports metric and imperial units. Includes dew point analysis. No signup needed.
