Machine Tapping Drill Size Calculator

INTRODUCTION

You drilled a 6.5 mm hole for an M8 tap.

You felt confident. You felt precise. You felt like a machinist.

The tap snapped in the hole. You blamed the tap quality.

Next job: a 1/4-20 UNC thread. You drilled 5.5 mm because "it looked right."

The thread stripped on the first assembly. You blamed the material. "Cheap aluminum."

But the real problem was the number.

You guessed the drill size. It did not know your thread percentage. It did not know your material hardness. It did not know you needed 6.8 mm for 75% thread engagement, not 6.5 mm.

Your hole was too tight. The tap overloaded. The chips jammed. The torque spiked.

This is what happens when you tap without a Machine Tapping Drill Size Calculator.

Tapping is not forgiving. It is the most common threading operation in machining — and the most expensive when wrong.

Too small drill? Excessive torque, tap breakage, poor thread form.

Too large drill? Weak threads, stripping, assembly failure.

Wrong thread percentage? Joint failure under load, rework, scrap.

A Machine Tapping Drill Size Calculator finds the exact drill diameter. The exact thread engagement. The exact cutting speed. The exact feed rate.

It tells you the drill size before you cut. The thread strength before you assemble. The tool life before you break.

In 2026, with CNC shops competing and job shops running thin margins, knowing your exact tapping parameters is not optional.

It is essential for every machinist, CNC operator, engineer, and anyone who wants threads that hold.

---

WHAT IS A MACHINE TAPPING DRILL SIZE CALCULATOR?

A Machine Tapping Drill Size Calculator is a tool that determines the exact drill bit diameter required to produce a specific internal thread with precise engagement percentage.

It uses standardized thread geometry formulas and engineering tables:

• Metric Threads (ISO) — M2 to M64, coarse and fine pitches

• Imperial Threads (UNC/UNF) — #0 to 2", coarse and fine series

• British Standard Whitworth (BSW) — 1/8" to 2"

• British Standard Fine (BSF) — 1/4" to 1-1/2"

• Pipe Threads (NPT/BSPT) — 1/16" to 2"

• Trapezoidal Threads (Tr) — Tr10 to Tr100

Standard inputs:

• Thread designation (M8, 1/4-20, 3/8-16, etc.)

• Thread standard (ISO, UNC, UNF, BSW, BSF, NPT)

• Thread engagement % (50%, 65%, 75%, 85%)

• Material type (steel, aluminum, brass, cast iron, stainless)

• Tap type (cutting tap, forming tap, spiral point, spiral flute)

• Hole depth (through hole or blind hole)

Outputs you get:

• Tap drill diameter in mm and inches

• Nearest standard drill size (metric and imperial)

• Thread engagement percentage

• Minor diameter of the thread

• Pitch diameter

• Cutting speed (SFM / m/min)

• RPM for the tapping operation

• Feed rate (mm/rev or in/rev)

• Recommended lubricant/coolant

• Tap drill chart for the selected thread family

It answers the questions every machinist asks:

"What drill size do I actually need for an M10 thread?"

"Why did my tap break even with the 'right' drill?"

"How strong will this thread be at 65% engagement?"

"Why do my threads strip in aluminum but hold in steel?"

---

HOW TO USE THE NUMOVIX MACHINE TAPPING DRILL SIZE CALCULATOR

Our calculator gives you instant, accurate drill sizes and tapping parameters in under 20 seconds.

Step 1:

Select your thread standard (Metric, Imperial, or Pipe).

Example: Metric ISO

---

Step 2:

Enter your thread designation.

Example: M8

---

Step 3:

Select your thread pitch (coarse or fine).

Example: M8 × 1.25 (coarse)

---

Step 4:

Select your desired thread engagement.

Example: 75% (standard for most applications)

---

Step 5:

Select your material.

Example: Mild Steel (AISI 1020)

---

Step 6:

Select your tap type.

Example: Cutting Tap, Spiral Point (through hole)

---

Step 7:

Click "Calculate Tap Drill."

You will instantly see:

Example: M8 × 1.25, 75% Engagement, Mild Steel

---

Drill Size Calculations:

| Parameter | Value |

| Theoretical Drill Diameter | 6.75 mm |

| Nearest Standard Drill (Metric) | 6.8 mm |

| Nearest Standard Drill (Imperial) | 17/64" (6.75 mm) |

| Thread Engagement | 75.3% |

| Minor Diameter | 6.647 mm |

| Pitch Diameter | 7.188 mm |

---

Tapping Parameters:

| Parameter | Value |

| Cutting Speed | 8–12 m/min (26–39 SFM) |

| Recommended RPM | 320–480 RPM |

| Feed Rate | 1.25 mm/rev |

| Coolant | Soluble oil or tapping fluid |

| Torque Estimate | 12–15 Nm |

---

Key Numbers:

• Drill Size: 6.8 mm (or 17/64")

• Thread Engagement: 75%

• RPM: 400 RPM (mid-range)

• Feed: 1.25 mm/rev

• Hole Type: Through hole = spiral point tap

• Blind hole: Use spiral flute tap instead

---

Example: 1/4-20 UNC, 65% Engagement, Aluminum 6061

| Parameter | Value |

| Theoretical Drill Diameter | 0.201" (5.11 mm) |

| Nearest Standard Drill (Imperial) | #7 (0.201") |

| Nearest Standard Drill (Metric) | 5.1 mm |

| Thread Engagement | 65.2% |

| Minor Diameter | 0.196" |

Tapping Parameters:

| Parameter | Value |

| Cutting Speed | 25–35 m/min (82–115 SFM) |

| Recommended RPM | 1,550–2,170 RPM |

| Feed Rate | 0.050 in/rev (1/20) |

| Coolant | Kerosene or aluminum tapping fluid |

| Tap Type | Spiral point or forming tap |

---

THE MATH BEHIND MACHINE TAPPING DRILL SIZE CALCULATION

Understanding the formulas helps you verify results and avoid broken taps.

---

Basic Formula for Metric Threads:

Drill Diameter = Major Diameter − Pitch

Example (M8 × 1.25):

Drill Diameter = 8 − 1.25 = 6.75 mm

This gives approximately 75% thread engagement for standard metric threads.

---

Thread Engagement Adjustment:

For different engagement percentages:

Drill Diameter = Major Diameter − (Pitch × Engagement Factor)

Where Engagement Factor:

• 50% engagement: 0.67 × Pitch

• 65% engagement: 0.83 × Pitch

• 75% engagement: 1.00 × Pitch (standard)

• 85% engagement: 1.15 × Pitch

Example (M8 × 1.25 at 65%):

Drill Diameter = 8 − (1.25 × 0.83) = 8 − 1.04 = 6.96 mm → use 7.0 mm

---

Imperial Thread Formula:

Drill Diameter = Major Diameter − (1 / TPI)

Example (1/4-20 UNC):

Drill Diameter = 0.250 − (1/20) = 0.250 − 0.050 = 0.200" (#7 drill)

For 65% engagement:

Drill Diameter = 0.250 − (0.050 × 0.83) = 0.250 − 0.0415 = 0.2085" → use 0.209" (#5)

---

Thread Strength Calculation:

Tensile Stress Area (Metric):

Aₛ = (π/4) × [(d₂ + d₃)/2]²

Where:

• d₂ = pitch diameter

• d₃ = minor diameter (approximate)

Example (M8 × 1.25):

d₂ = 7.188 mm

d₃ = 6.647 mm

Aₛ = (π/4) × [(7.188 + 6.647)/2]² = 0.785 × 47.82 = 36.6 mm²

Proof Load (Steel, 400 MPa):

Load = 36.6 × 400 = 14,640 N ≈ 1,493 kgf

---

Cutting Speed Formula:

RPM = (Cutting Speed × 1000) / (π × Drill Diameter)

Example (M8 in steel, 10 m/min):

RPM = (10 × 1000) / (3.1416 × 6.8) = 10,000 / 21.36 = 468 RPM

---

Feed Rate:

Feed = Pitch (for single-start threads)

Example (M8 × 1.25):

Feed = 1.25 mm/rev

For CNC: G95 mode, F1.25

---

Complete Real Example:

Vikram's CNC Job Shop Project:

Starting Point:

• Customer order: 500 aluminum brackets with M6 threads

• Material: Aluminum 6061-T6

• Thread: M6 × 1.0

• Engagement required: 65% (customer specification)

• Machine: CNC VMC, 10,000 RPM spindle

---

Week 1: The Guess Approach

Vikram thinks: "M6 tap, so 5 mm drill. That's what everyone uses."

He programs 5.0 mm drill, M6 × 1.0 tap at 800 RPM.

First 50 parts:

• Tap breaks on part 12

• Tap breaks on part 31

• Thread gage fails on part 44 (oversized, 55% engagement)

He blames the tap brand. Switches to a "premium" tap.

Same result. More broken taps.

He increases RPM to 1,200. "More speed = cleaner cut."

Result: Tap breaks faster. Aluminum welds to tap flutes.

Net result: $400 in broken taps. 150 scrapped parts. 2 days lost.

---

Week 2: Discovers the Calculator

Vikram uses the Numovix Machine Tapping Drill Size Calculator.

• Thread: M6 × 1.0

• Material: Aluminum 6061-T6

• Engagement: 65%

• Hole type: Through hole

Calculator Results:

| Parameter | Value |

| Theoretical Drill Diameter | 5.17 mm |

| Nearest Standard Drill | 5.1 mm |

| Actual Engagement | 68% |

| Cutting Speed | 30 m/min |

| Recommended RPM | 1,870 RPM |

| Feed Rate | 1.0 mm/rev |

| Coolant | Kerosene-based tapping fluid |

| Tap Type | Spiral point, 2-flute |

He realizes:

• He used 5.0 mm drill = 83% engagement. Way too tight for aluminum.

• 800 RPM was too slow. Aluminum needs high speed for clean chips.

• No coolant. Dry tapping in aluminum = built-up edge and galling.

• Wrong tap type. Used hand tap in machine. Wrong geometry.

---

New Approach:

Target: Exact drill size, correct speed, proper coolant, right tap

Program: 5.1 mm drill, spiral point tap at 1,800 RPM

Coolant: Flood kerosene-based tapping fluid

Feed: 1.0 mm/rev (rigid tapping)

Depth: 12 mm (1.5× diameter for engagement)

Results for remaining 350 parts:

• Zero broken taps

• 100% thread gage pass

• Tap lasted 450 holes (vs. 12 holes before)

• Cycle time: 8 seconds per hole

Cost savings:

• Taps: $15 each × 0 broken = $0

• Scrap: 0 parts

• Time saved: 2 days

He spent less money and got production-quality results.

Why? Because he respected the math.

---

TAP DRILL SIZES BY THREAD TYPE

| M3 | 0.5 | 2.5 | 2.6 | 2.7 | Steel/Aluminum |

| M4 | 0.7 | 3.3 | 3.4 | 3.5 | Steel/Aluminum |

| M5 | 0.8 | 4.2 | 4.3 | 4.4 | Steel/Aluminum |

| M6 | 1.0 | 5.0 | 5.1 | 5.2 | Steel/Aluminum |

| M8 | 1.25 | 6.8 | 6.9 | 7.0 | Steel/Aluminum |

| M10 | 1.5 | 8.5 | 8.6 | 8.7 | Steel/Aluminum |

| M12 | 1.75 | 10.3 | 10.4 | 10.5 | Steel/Aluminum |

| M16 | 2.0 | 14.0 | 14.1 | 14.2 | Steel/Aluminum |

| 1/4-20 | — | #7 (0.201") | #5 (0.209") | 1/4" (0.213") | Steel |

| 3/8-16 | — | 5/16" (0.313") | Q (0.332") | R (0.339") | Steel |

| 1/2-13 | — | 27/64" (0.422") | 29/64" (0.453") | 15/32" (0.469") | Steel |

---

WHY EVERY MACHINIST NEEDS A MACHINE TAPPING DRILL SIZE CALCULATOR

1. Know Your Drill Size

Tapping is permanent. You cannot "add material back" to an oversized hole.

Drill too small? Tap breaks, hole scrap.

Drill too large? Thread strips, joint fails.

The calculator shows the exact diameter. No guesswork.

---

2. Stop Breaking Taps

"I used a 5 mm drill for M6 because that's what the old chart says."

At 83% engagement in steel, torque is 40% higher than at 75%.

In stainless steel? Tap breaks every time.

The calculator accounts for material and engagement. You tap with confidence.

---

3. Get Thread Strength Right

More engagement does not always mean stronger threads.

• 50% engagement: 50% of full thread strength

• 75% engagement: 85% of full thread strength

• 100% engagement: 100% strength, but 3× torque required

Beyond 75%, strength gains are minimal. Torque increases dramatically.

The calculator finds the engineering sweet spot.

---

4. Avoid Assembly Failures

Threads that strip during assembly cost more than broken taps.

Customer rejects. Warranty claims. Reputation damage.

The calculator ensures your threads meet class of fit requirements:

• Class 2B: Standard fit (most applications)

• Class 3B: Close fit (precision assemblies)

---

5. Optimize CNC Cycle Times

Wrong RPM = slow cycle or broken tool.

Wrong feed = chatter, poor finish, oversized threads.

The calculator gives optimized cutting parameters for your machine and material.

---

6. Understand Why Your Threads Failed

Your senior machinist: Used calculator, 65% engagement, proper coolant, spiral flute tap.

You: Guessed drill size, dry tapped, used wrong tap.

Same drawing. Different methods. Different results.

The calculator explains the difference.

---

KEY FACTORS THAT AFFECT TAPPING SUCCESS

Thread Engagement Percentage:

The most critical factor in tap life and thread strength.

• 50% engagement: Easy tapping, weak threads, used in soft materials

• 65% engagement: Balanced strength, standard for aluminum and brass

• 75% engagement: Standard for steel, good strength, moderate torque

• 85% engagement: High strength, high torque, risk of tap breakage

• 100% engagement: Maximum strength, 2–3× torque, not recommended

Every 10% increase in engagement increases torque by approximately 25%.

---

Material Hardness:

• Aluminum (6061): Use 65% engagement, high RPM, kerosene coolant

• Mild Steel (1020): Use 75% engagement, moderate RPM, soluble oil

• Stainless Steel (304): Use 65% engagement, low RPM, heavy-duty tapping fluid

• Cast Iron: Use 75–80% engagement, dry or air blast

• Brass/Bronze: Use 65% engagement, high RPM, no coolant needed

---

Tap Geometry:

• Spiral Point: For through holes, pushes chips ahead

• Spiral Flute: For blind holes, pulls chips out

• Straight Flute: General purpose, cheapest

• Forming Tap: No chips, displaces material, needs 65% engagement max

• Bottoming: For shallow blind holes, 1–2 thread chamfer

---

Cutting Speed (SFM):

| Material | Cutting Speed (m/min) | Cutting Speed (SFM) |

| Aluminum | 25–35 | 80–115 |

| Brass | 20–30 | 65–100 |

| Mild Steel | 8–12 | 26–39 |

| Stainless Steel | 4–8 | 13–26 |

| Cast Iron | 10–15 | 33–50 |

Too fast = heat, tap welding, poor finish.

Too slow = work hardening (especially stainless), torn threads.

---

Coolant and Lubrication:

• Steel: Soluble oil, sulfurized cutting oil

• Stainless: Chlorinated or sulfurized heavy-duty oil

• Aluminum: Kerosene, specialized aluminum tapping fluid

• Cast Iron: Dry or air blast (coolant causes rust)

• Brass: Dry or light mineral oil

---

COMMON MISTAKES MACHINISTS MAKE

Mistake 1: Guessing the Drill Size

"I always use 6.5 mm for M8."

Result: 83% engagement in steel. Tap breaks. Hole scrap.

Or 6.8 mm in aluminum. 55% engagement. Thread strips.

Always calculate. Never guess.

---

Mistake 2: Ignoring Thread Engagement

"I want maximum strength, so I drill small for 90% engagement."

Result: Tap breaks in stainless steel. Thread is actually weaker because the tap ripped the material.

75% is the standard for a reason. More is not better.

---

Mistake 3: Using the Wrong Tap for the Hole Type

Using a spiral point tap in a blind hole.

Result: Chips pack at bottom. Tap breaks. Hole damaged.

Through hole = spiral point. Blind hole = spiral flute.

---

Mistake 4: Wrong RPM

"I run all taps at 500 RPM."

Result: In aluminum, chips weld to tap. In stainless, work hardening occurs.

Match RPM to material and diameter. The calculator knows.

---

Mistake 5: Dry Tapping

"It's just a few holes. No coolant needed."

Result: Heat buildup. Tap dulls in 10 holes. Thread finish is poor.

Always use coolant. Even a drop of oil is better than nothing.

---

Mistake 6: Not Using Rigid Tapping on CNC

"Floating tap holder is safer."

Result: Inconsistent thread depth. Oversized threads. Poor repeatability.

Rigid tapping with synchronous feed = better threads, longer tap life.

---

Mistake 7: Wrong Feed Rate in CNC

"I use G95 but forgot to set F = pitch."

Result: M8 × 1.25 programmed at F1.0. Z-axis lags spindle. Tap breaks instantly.

Feed must equal pitch exactly. M6 = F1.0. M8 = F1.25. M10 = F1.5.

---

PRO TIPS TO TAP LIKE A PRO

Tip 1: Calculate Before Every New Material

Same thread, different material = different drill size.

M8 in aluminum: 6.9 mm (65% engagement).

M8 in steel: 6.8 mm (75% engagement).

The calculator adjusts automatically.

---

Tip 2: Use Forming Taps for Ductile Materials

In aluminum and brass, forming taps produce stronger threads with no chips.

Requirements:

• Drill size 3–5% larger than cutting tap

• Material must be ductile (elongation > 10%)

• 65% engagement maximum

Result: 2× tap life, stronger threads, no chip evacuation issues.

---

Tip 3: Peck Tapping for Deep Holes

For holes deeper than 2× diameter:

• Peck 3–4 threads

• Retract to break chip

• Repeat

Prevents chip packing and tap breakage in blind holes.

---

Tip 4: Use Through-Coolant Taps When Possible

High-pressure coolant through the tap flushes chips from blind holes.

Essential for:

• Stainless steel

• Deep holes (>2× diameter)

• High-production environments

---

Tip 5: Verify with Thread Gage

Always check first article with:

• Go gage: Must thread fully by hand

• No-go gage: Must not thread more than 2 turns

If go gage is tight, drill is too small. If no-go enters, drill is too large.

---

Tip 6: Keep a Tapping Log

Record for each job:

• Thread size and pitch

• Drill size used

• Material

• RPM and feed

• Tap type and brand

• Number of holes per tap

Build your own database of what works in your shop.

---

Tip 7: Chamfer the Hole Entrance

A 45° chamfer (slightly larger than major diameter) helps:

• Tap start straight

• Prevent burrs

• Guide the tap into the hole

---

QUICK SUMMARY

Before you use the calculator, remember these key points:

• Drill Diameter = Major Diameter − Pitch (for 75% metric threads)

• 75% engagement is standard for steel — strong threads, reasonable torque

• 65% engagement is standard for aluminum/brass — prevents tap breakage

• Thread engagement above 85% is rarely needed — excessive torque, minimal strength gain

• RPM = (Cutting Speed × 1000) / (π × D) — match speed to material

• Feed = Pitch exactly — in CNC, F must equal thread pitch

• Through hole = spiral point tap — pushes chips ahead

• Blind hole = spiral flute tap — pulls chips out

• Always use coolant — even a drop of oil extends tap life dramatically

• Forming taps for aluminum/brass — no chips, stronger threads

• Rigid tapping on CNC — synchronous spindle and Z-axis for precision

• Verify with go/no-go gages — first article inspection is mandatory

• Peck tap deep holes — retract every 3–4 threads to break chips

---

FREQUENTLY ASKED QUESTIONS

Q1: What is thread engagement percentage?

Thread engagement is the percentage of full thread height that is actually formed in the material.

75% engagement means the thread crest is 75% of theoretical full height.

Higher engagement = stronger threads but higher tapping torque.

The calculator finds the drill size that produces your target engagement.

---

Q2: Which engagement percentage should I use?

• 50%: Soft plastics, cast iron, emergency repairs

• 65%: Aluminum, brass, bronze, stainless steel (prevents tap breakage)

• 75%: Mild steel, alloy steel, general machining (standard)

• 85%: High-strength requirements, limited material thickness

• 100%: Rarely used, requires special taps, very high torque

Match engagement to material hardness and application requirements.

---

Q3: Why did my tap break even with the "right" drill size?

Common causes:

• Engagement too high for the material (e.g., 80% in stainless)

• RPM too low causing work hardening

• No coolant causing heat buildup and chip welding

• Wrong tap type (spiral point in blind hole)

• Dull tap — taps wear out, replace regularly

• Misalignment — tap not perpendicular to hole

• Chip packing in deep blind holes

The drill size is only one factor. Speed, coolant, and tap geometry matter equally.

---

Q4: Can I use the same drill size for different materials?

No. Same thread, different material = different optimal engagement.

Example M8:

• Steel: 6.8 mm (75% engagement)

• Aluminum: 6.9 mm (65% engagement)

• Stainless: 6.9 mm (65% engagement, lower torque)

The calculator adjusts for material automatically.

---

Q5: How do I calculate tap drill for pipe threads (NPT/BSPT)?

Pipe threads are tapered. The calculator uses:

Drill Size = Nominal Pipe Size − Taper Allowance

Example (1/4" NPT):

• Theoretical drill: 0.422" (letter T drill)

• Taper: 1:16

• The calculator provides the correct drill for the starting thread

Always use a taper tap for NPT threads. Never use a bottoming tap.

---

Q6: What is the difference between a cutting tap and a forming tap?

Cutting tap: Removes material to create threads. Produces chips. Works in all materials.

Forming tap: Displaces material without cutting. No chips. Requires ductile material (aluminum, brass, mild steel). Produces stronger threads. Needs larger drill size (3–5% larger).

The calculator provides drill sizes for both types.

---

Q7: Do I need different parameters for CNC vs. manual tapping?

Yes.

Manual tapping:

• Use tapping fluid

• Turn 1/2 revolution forward, 1/4 back to break chips

• Keep tap perpendicular with tapping guide

CNC tapping:

• Use rigid tapping (synchronous spindle)

• Feed = pitch exactly

• Use through-coolant if available

• Program peck cycles for deep holes

The calculator provides parameters for both methods.

---

RELATED CALCULATORS

Explore our full suite of free machining and engineering tools:

• Drill Speed and Feed Calculator

• End Mill Speed and Feed Calculator

• Thread Turning Calculator

• Knurling Calculator

• Countersink Calculator

• Reamer Drill Size Calculator

• Sheet Metal Bend Calculator

• CNC G-Code Generator

• Surface Finish Calculator

---

FINAL THOUGHTS

Tapping is not forgiving.

It does not care about your experience. It does not care about your expensive tap. It does not care about your deadline.

It only cares about the drill size. The engagement. The speed. The coolant. The tap geometry.

The Machine Tapping Drill Size Calculator does not cut the thread.

It guides you.

It tells you: "This is the drill. This is the engagement. This is the speed. This is where guessing ends and machining begins."

Below the right parameters, you are not threading. You are making expensive scrap and broken taps.

At the right parameters, with proper technique, you are machining.

Threads hold. Assemblies pass. Customers approve. Tool life extends.

Before you pick up another drill bit, calculate your tap drill.

Before you break another tap, calculate your tap drill.

Before you wonder why threads strip and customers complain, calculate your tap drill.

Know your drill size. Respect the engagement. Machine from a place of precision, not guesswork.

That is how you tap something that holds.

That is how you thread without regret.

That is how you produce parts that pass inspection every time.

---

DISCLAIMER

This article is for educational and informational purposes only.

Tapping calculations, drill sizes, and machining guidelines are general estimates and vary significantly by machine condition, tool quality, material batch, and specific application requirements.

The examples provided are illustrative and based on standard engineering practices (ISO 68-1, ASME B1.1, Machinery's Handbook).

Actual tapping requirements depend on:

• Machine rigidity and spindle condition

• Tap quality and coating (TiN, TiCN, TiAlN)

• Material hardness and composition variations

• Coolant type and delivery method

• Hole depth and geometry (through vs. blind)

• Operator skill and setup accuracy

Always consult a qualified manufacturing engineer, tool specialist, or experienced machinist before making critical threading operations, especially for aerospace, medical, or safety-critical applications.

Numovix does not provide engineering advice, manufacturing supervision, or tool selection services.

Our calculator results are estimates and should not replace professional machining guidance or tool manufacturer recommendations.

If you are machining critical components (aerospace fittings, medical devices, pressure vessels), follow industry standards and use certified tooling with documented parameters.

Machine Tapping Drill Size Calculator | Find Perfect Tap Drill for Metric & Imperial Threads | Numovix

Free machine tapping drill size calculator. Find exact tap drill sizes for metric (M2–M64) and imperial (UNC, UNF, BSW, BSF) threads. Calculate thread percentage, drill diameter, and cutting speeds instantly. No signup needed.
